Great Plains TA520S Operator Manual User Manual
Page 41
3/18/2005
500-061M
39
MeterCone® Nozzles 20" Spacing -
Height 19" to 21" Angle Fixed 20˚
*For Post Emerge Applications where finer droplets are required use 40 PSI or greater.
Nozzle
Size
Pressure
PSI
Gallons Per Acre At Miles Per Hour
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
12.5
10.00
92.81
74.25
61.88
53.04
46.41
41.25
37.13
33.75
30.94
15.00
113.60
90.88
75.74
64.92
56.80
50.49
45.44
41.31
37.87
20.00
131.42
105.14
87.62
75.10
65.71
58.41
52.57
47.79
43.81
25.00
147.02
117.61
98.01
84.01
73.51
65.34
58.81
53.46
49.01
30.00
161.87
129.49
107.91
92.49
80.93
71.94
64.75
58.86
53.96
35.00
171.52
137.21
114.35
98.01
85.76
76.23
68.61
62.37
57.17
40.00*
185.63
148.50
123.75
106.07
92.81
82.50
74.25
67.50
61.88
Nozzle
Size
Pressure
PSI
Gallons Per Acre At Miles Per Hour
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
15.0
10.00
111.38
89.10
74.25
63.64
55.69
49.50
44.55
40.50
37.13
15.00
136.62
109.30
91.08
78.07
68.31
60.72
54.65
49.68
45.54
20.00
157.41
125.93
104.94
89.95
78.71
69.96
62.96
57.24
52.47
25.00
175.97
140.78
117.32
100.56
87.99
78.21
70.39
63.99
58.66
30.00
193.05
154.44
128.70
110.31
96.53
85.80
77.22
70.20
64.35
35.00
206.42
165.13
137.61
117.95
103.21
91.74
82.57
75.06
68.81
40.00*
222.75
178.20
148.50
127.29
111.38
99.00
89.10
81.00
74.25
