73 Simba X-Press
601-339P
2014-01-22
Hydraulic Fold Circuit (5.5m & 6.6m)
1 810-814C MANIFOLD BLOCK
2 841-787C AD 1/2MBSPP BLKHD W/LN
3 841-792C WASHER 1/2BSPP BONDED
4 841-793C WASHER 3/8BSPP BONDED
5 841-906C QUICK RELEASE MALE - ½” BSP
6 851-078C PLUG 3/8 M BSPP
7 851-080C PLUG 1/4 M BSPP
8 851-082C PLUG 1/4 M BSPP
9 851-083C CAP 1/2 F BSPP
10 851-149C AD 1/2MBSPP 3/8MBSPP
11 851-157C CAP FOR MALE - YELLOW
12 851-184C AD 1/2MBSP 1/2MBSP
13 851-185C EL 1/2FBSP 1/2FBSP
14 851-186C TE 1/2FBSP 1/2MBSP 1/2MBSP
15 851-187C GAUGE ADAPTOR 1/4BSP
16 851-188C ACCUMULATOR 1.4L DIAPHRAGM 10B
17 851-190C PRESSURE GAUGE 250BAR
18 851-191C ACCUMULATOR 0.7L 10BAR
19 851-192C CONNECTOR BLOCK 3/8BSP
20 851-200C CYLINDER - Ø90X400 - 45
21 851-316C HH1/2R2 4850MM 1/2BSP/1/2BSP90
22 851-317C HH1/2R2 2050MM 1/2BSP/1/2BSP90
23 851-318C HH1/2R2 1950MM 1/2BSP/1/2BSP90
24 851-325C HH1/2R2 650MM 1/2BSPF90/90@0°
25 851-326C HH1/2R2 1050MM 1/2BSPF90/90@0°
26 851-327C HH1/2R2 650MM 1/2BSPF90/90@90°
27 851-329C HH1/2R2 1050MM1/2BSPF90/90@90°
28 851-319C HH1/2R2 650MM 1/2FBSP/1/2FBSP
29 851-328C HH1/2R2 650MM1/2BSPF90/90@270°
30 851-330C HH1/2R21050MM1/2BSPF90/90@270°
31 851-189C GAUGE ADAPTOR 1/4FBSP 1/4MBSP
Parts
Item Part No. Part Description Comments
