55 Simba X-Press
601-339P
2014-01-22
Scraper Rail (For DDL600, ML & HD Roll)
1 601-084H SCRAPER RAIL RH - 2300MM
601-085H SCRAPER RAIL LH - 2300MM
601-086H SCRAPER RAIL RH - 2850MM
601-087H SCRAPER RAIL LH - 2850MM
601-088H SCRAPER RAIL RH - 3305MM
601-089H SCRAPER RAIL LH - 3305MM
2 603-534D SCRAPER PLATE 150MM
3 604-037K SCRAPER ASSEMBLY DDL150 COMPLETE (SUITS ML & HD ROLLS)
4 604-083K SCRAPER ASSEMBLY DDL200 COMPLETE
5 604-247D SCRAPER PLATE
6 803-280C NUT HEX NYLOCK M10X1.5 PLT
7 803-281C NUT HEX NYLOCK M12X1.75 PLT
8 803-282C NUT HEX M16X2.00 NYLON INSERT
9 804-162C WASHER FLAT M10 PLT
10 804-246C WASHER FLAT M12 PLT
11 804-247C WASHER FLAT M16 PLT
12 806-236C U-BOLT M16-2.00 X 101 X 190
13 812-414C SCRAPER CLAMP PLATE
14 812-415C SCRAPER STEM
15 842-025C HHCS M10X1.5X45 GR8.8
16 842-026C HHCS M12X1.75X100 GR8.8
Parts
Item Part No. Part Description Comments
