Great Plains X-Press Parts Manual - Manual (Page 65)

65 Simba X-Press
601-339P
2014-01-22
1 601-093H CHAMBER MOUNT LH
2 601-094H CHAMBER MOUNT RH
3 601-319D BULKHEAD
4 601-354D PLATE 8MM
5 601-355D PLATE 8MM
6 601-433D RETAINING PLATE
7 601-434D PALM COUPLER STOWAGE
8 802-609C HHCS M10X1.5X30 GR8.8
9 802-703C HHCS M16X2.0X40 GR8.8
10 803-279C NUT HEX M10X1.5 PLT
11 803-281C NUT HEX NYLOCK M12X1.75 PLT
12 803-282C NUT HEX M16X2.00 NYLON INSERT
13 804-158C WASHER SPRING LOCK M10 PLT
14 804-226C WASHER LOCK M6 PLT
15 804-246C WASHER FLAT M12 PLT
16 804-247C WASHER FLAT M16 PLT
17 842-021C HHCS M6X1X20 GR8.8
18 842-171C HHCS M12X1.75X150 GR8.8
19 851-079C CAP 3/8 F BSPP
20 891-311C BRAKE CHAMBER
21 891-312C AIR TANK - 20L
22 891-366C PALM COUPLING
23 891-368C AIR COIL
24 891-369C AIR COIL
25 891-370C LINE FILTER
26 891-373C SHUNT VALVE
27 891-374C RELAY-EMERGENCY VALVE
28 891-375C RESERVOIR DRAIN VALVE
29 891-377C M22M X M16F REDUCER
30 891-378C STUD COUPLING
31 891-379C SWIVEL ELBOW
32 891-380C SWIVEL ELBOW
33 891-381C SWIVEL ELBOW
34 891-382C BLANKING PLUG
35 891-390C AIR TANK MOUNTING STRAP
36 891-435C AIR HOSE FITTING M16 FIXED
37 891-436C AIR HOSE FITTING M16 SWIVEL
38 891-437C BLANKING PLUG M22
Brakes - Air
Parts
Item Part No. Part Description Comments
