7 Simba X-Press
601-339P
2014-01-22
Parts
Item Part No. Part Description Comments
Drawbar Assembly
1 601-092H FRONT LIGHT MOUNT
2 601-150H HOSE MAST - X-PRESS
3 601-219H PIN Ø30X138
4 601-310H X-PRESS DRAWBAR ISO PLATE
5 601-415D SOCKET PLATE 12N
6 601-417D LIGHT ARM MOUNT
7 611-156D HOSE STOWAGE PLATE
8 802-683C HHCS M8X1.25X45 GR8.8
9 802-714C HHCS M8X1.25X25 GR8.8
10 802-723C HHCS M12X1.75X45 YELW DIE G8.8
11 802-997C HHCS M10X1.5X25 GR8.8
12 803-280C NUT HEX NYLOCK M10X1.5 PLT
13 803-281C NUT HEX NYLOCK M12X1.75 PLT
14 803-354C NUT HEX M6-1
15 803-422C NUT HEX M8X2.00 NYLON INSERT
16 804-160C WASHER FLAT M6 PLT
17 804-161C WASHER FLAT M8 PLT
18 804-162C WASHER FLAT M10 PLT
19 804-244C WASHER FLAT M20 PLT
20 804-246C WASHER FLAT M12 PLT
21 804-265C WASHER FLAT M39
22 805-448C LYNCH PIN CAT 1
23 806-239C U-BOLT M12X1.75 X 42 X 70
24 814-460C NUT HEX M36X4 NYL INSERT
25 817-928C MANUAL HOLDER
26 833-610C LIGHT BOARD FRH
27 833-611C LIGHT BOARD FLH
28 841-660C STAUFF CLAMP-TOP PLATE
29 841-662C STAUFF CLAMP-1/2” PAIR
30 842-023C HHCS M8X1.25X25 GR8.8 FTHD
31 842-105C HHCS M36X4X200 GR8.8
32 842-117C HHCS M8X1.25X110 GR8.8
33 842-119C HHCS M12X1.75X65 GR8.8
34 842-120C HHCS M6X1X25 GR8.8 FTHD
35 842-201C HHCS M20X2.5X70 GR10.9
36 891-291C SIDE MARKER LH
37 891-292C SIDE MARKER RH
