13 Simba X-Press
601-339P
2014-01-22
Crossbar Linkages
Parts
Item Part No. Part Description Comments
1 603-084H HITCH CROSSBAR - CAT 3
2 603-085H HITCH CROSSBAR - CAT 4
3 603-091H HITCH PLATE CAT 4N
4 603-092H YOKE BRACE CAT 4
5 603-198V CAT 3 HITCH PLATE ASSEMBLY
6 603-199V CAT 3 HITCH PLATE ASSEMBLY
7 603-200K CAT 4 YOKE BRACE ASSEMBLY
8 603-516D CLAMP PLATE C/W HOLES
9 611-156D HOSE STOWAGE PLATE
10 802-997C HHCS M10X1.5X25 GR8.8
11 803-438C NUT HEX M24X3 PLT
12 804-158C WASHER SPRING LOCK M10 PLT
13 804-162C WASHER FLAT M10 PLT
14 804-255C WASHER FLAT M24 - OD50MM
15 805-468C LYNCH PIN CAT 3
16 827-113C BALL CAT 3 LOWER Ø37
17 827-129C BUSH SPRUNG - Ø45XØ36X40
18 842-131C HHCS M24X3X120 GR8.8
