53 Simba X-Press
601-339P
2014-01-22
1 601-015S SCJ50 BEARING COMPLETE
2 601-150D STUB AXLE END WASHER
3 601-309D PILLAR RH SHOWN
601-312 PILLAR LH
4 803-281C NUT HEX NYLOCK M12X1.75 PLT
5 803-393C NUT HEX NYLOCK M20X2.5
6 804-244C WASHER FLAT M20 PLT
7 804-246C WASHER FLAT M12 PLT
8 842-024C HSHCS M12X1.75X35 GR8.8
9 842-101C HSFCHCS M20X2.5X80 GR8.8
10 842-192C HSFCHCS M12X1.75X65 GR10.9
Pillar for DDL600, ML, V & HD Rolls
Parts
Item Part No. Part Description Comments
