Great Plains P17917B Operator Manual - Manual (Page 99)

99 X-Press
Operating Instructions
7. Parts and Assembly
AS3237 AQUEEL ROLL 2 ASSEMBLY - 4.0m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P10944 SCREW M12x50 GR10.9 CSK 8
2 P13548 RING - RETAINING 2
3 P14810 AQUEEL 2 WHEEL - 125mm 6
4 P14815 AQUEEL 2 WHEEL - 150mm 21
5 P15921 ROLL TUBE CCR 3935mm 1
