73 X-Press
Operating Instructions
7. Parts and Assembly
AS3598 DDLIGHT ROLL 2.5m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P02008 NUT LOCK M16 'TYPE T' 6 DIN 985
2 P02600 WASHER FLAT M10 34
3 P02602 WASHER FLAT M16 6
4 P03704 BOLT U M16 GR8.8 145x117 3
5 P05534 NUT LOCK M10 51
6 P12959 RING DDL550 - Ø358 32
7 P13942 BOLT M10x25 DOME SQ. 17
8 P13961 BOLT U M10 GR8.8 71x88 17 H34284302
9 P15085 SCRAPER PLATE 17
10 P15130 RING - RETAINING 2
11 P15148 SCREW M16x50 GR10.9 CSK 8
12 P15829 ROLL TUBE 2442mm 1
13 P15912 SPACER 27mm DDL 2
14 P15913 SPACER 56mm DDL 15
15 P16473 STEM - SCRAPER DDL600 CB 17
16 P16699 2.5M SCRAPER RAIL H 1
