AS2266 HYDRAULIC HOSE LAYOUT
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P07624 HA 3/8"x1830 2
2 P14788 HA 3/8"x1000 90° 2
3 P14792 HA 3/8"x800 90° 2
4 P14793 HA 3/8"x400 90° 1
