X-Press

Operating Instructions

18

4. Adjustment/Operation

4.1 Description

Fig. 4.01: Simba Great Plains Mounted X-Press - Rigid

1. 3 Point Linkage

2. Discs

3. DD Light Roller

4. Roll Depth Adjusters

5. Disc Angle Adjusters

1. 3 Point Linkage

2. Discs

3. DD Light Roller

4. Roll Depth Adjusters

5. Disc Angle Adjusters

6. Hydraulic Fold Cylinders

Fig. 4.02: Simba Great Plains Mounted X-Press - Folding

1

2

5

4

3

1

4. Adjustment / Operation

2

3

5

4

6
