Great Plains P17917B Operator Manual - Manual (Page 107)

107 X-Press
Operating Instructions
7. Parts and Assembly
AS3607 DDLIGHT ROLL RH 4.0m FW
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P02008 NUT LOCK M16 'TYPE T' 4 DIN 985
2 P02600 WASHER FLAT M10 26
3 P02602 WASHER FLAT M16 4
4 P03704 BOLT U M16 GR8.8 145x117 2
5 P05534 NUT LOCK M10 39
6 P12959 RING DDL550 - Ø358 26
7 P13942 BOLT M10x25 DOME SQ. 13
8 P13961 BOLT U M10 GR8.8 71x88 13
9 P15085 SCRAPER PLATE 13
10 P15130 RING - RETAINING 2
11 P15148 SCREW M16x50 GR10.9 CSK 8
12 P15832 ROLL TUBE 2022mm 1
13 P15913 SPACER 56mm DDL 13
14 P16473 STEM - SCRAPER DDL600 CB 13
15 P16643 2M SCRAPER RAIL H 1
