57 X-Press
Operating Instructions
7. Parts and Assembly
AS3825 WING ASSEMBLY RH
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS3210 DISC UNIT ASSEMBLY RH 8
2 AS3211 DISC UNIT ASSEMBLY LH 8
3 P00015 BOLT M24x75 GR. 8.8 2
4 P00874 BOLT M20x70 GR. 8.8 4
5 P01704 BOLT M16x50 GR8.8 32
6 P01901 BOLT M16x80 GR. 8.8 32
7 P02008 NUT LOCK M16 'TYPE T' 64
8 P02009 NUT LOCK M20 4
9 P02010 NUT LOCK M24 2
10 P02483 LYNCH PIN CAT 1 1
11 P02488 PIN SPLIT Ø5x75 2
12 P02602 WASHER FLAT M16 52
13 P02604 WASHER FLAT M24 Ø50 4
14 P11462 DISC BLADE Ø515x6 16
15 P12620 TOP PLATE 16
16 P12621 SPACER Ø36xØ16.5x31mm 32
17 P12622 TRACK ARM 16
18 P12783 LYNCH PIN CAT 0 16
19 P12810 NUT CASTLE M24 16
20 P12815 BOLT M24x185 STRUCTURAL GR 8.8 16
21 P12886 Ø24xØ16x13mm SPACER BUSH 16
22 P12928 TRACK ROD FRONT LH 4.6SL X-PRESS 1
23 P14055 SPACER BUSH - 10mm 4
24 P14063 TRACKROD REAR RH - 8 HOLES 550mm 1
25 P14069 BOLT M39x200 2
26 P14070 SLOTTED NUT M39 2
27 P14071 PIN Ø30x115 1
28 P14987 DISC FRAME RH 1
29 P15438 ANGLE GUIDE 2
30 P17076 ADJUSTER 350-600 2
31 P17335 ROLL LINKAGE BUSH 2
