Great Plains Mfg., Inc.
Installation Instructions 9
02/02/2007 402-231M
Initialize the System
51. Turn on the seed monitor, and configure it per the
DICKEY-john instruction manual. The new pickup
wheel has 30 teeth.
52. Re-install seed hoppers and meters.
Parts Lists
New Parts Included in the 402-234A Update Kit:
Existing Parts Affected:
Callout Quantity Part No. Part Description
1 402-231M This manual
1 402-262D DISC, MAG PICKUP
1 402-426D HALL EFFECT SENSOR MNT- PRE 07
8 403-216S SEED TUBE FPU TB,CLIP W/ HOLE
16 404-146D BUSHING, IDLER PIVOT
56 800-244C CABLE TIE .19X15 PANDU BT4S-C0
2 802-005C HHCS 1/4-20X1 GR5
2 803-006C NUT HEX 1/4-20 PLT
2 804-006C WASHER LOCK SPRING 1/4 PLT
16 817-713C CHAIN IDLER
1 833-451C DJ HALL EFFECT SENSOR W/NUTS
1 833-452C DJ SENSOR TO RADAR 15.5 EXT
1 833-453C DJ RADAR EXTENSION 25 FT.
Callout Qty Part No. Part Description Part Disposition
1 402-124H CONTACT WHL DRIVE SHIELD LH Left in place, but modified
8 404-087H IDLER WELDMENT Left in place
16 404-146D BUSHING, IDLER PIVOT Removed. Not re-used
8 404-149D PLATE, IDLER RETAINER Removed and re-installed
16 802-251C RHSNB 5/16-18X2 1/4 GR5 Left in place
16 803-043C NUT HEX WHIZ 5/16-18 PLT Removed and re-installed
1 804-029C WASHER FLAT SAE 1 Removed and re-installed
1 805-021C PIN COTTER 1/4 X 2 PLT Removed and re-installed
1 808-147C SPKT 40C15 X 7/8 HEX BORE Removed and re-installed
1 817-131C KNOB, TRANS. SHIELD Removed and re-installed
16 817-333C IDLER ROLLER Removed. Not re-used
1 817-335C LH CONTACT DRIVE CHAIN COVER Removed, modified and re-installed
8 817-604C 25P SEED TUBE W/DJ HR SENSOR Removed. Seed tube not re-used.
Sensor and firmer (if any) re-used.
