148-679M 5/9/2007
Great Plains Mfg., Inc.
13 Installation Instructions
148-667A NTA2000 Small Seeds Package
Your kit includes:
8 123-190D SEED CUP COVER
1 136-051D CHAIN RL #40 166 PITCHES
1 148-657L NTA2000 SGS 40 BOX ASSEMBL
1 148-660K NTA2000 SGS DRIVE ASSEMBLY
1 148-662K NTA2000 SGS LOWER DRIVE AS
1 148-665K NTA2000 SGS FDR CUP DRIVE
1 148-672H NTA2000 SGS HOSE SUPPORT B
1 148-679M NTA2000 SMALL SEEDS MANUAL
1 148-680H NTA2000 SGS CALABRATION CR
2 148-844D NTA1300 SML SDS CAL TRAY C
1 248-228D NTA2000 SGS OUTER DRIVE SH
1 248-230D NTA2000 SGS INNER DRIVE SH
1 248-232D NTA2000 SGS FINAL DRIVE SH
1 248-236D NTA2000 SGS MOUNT SPACER P
4 248-247D NTA2000 SGS HAND RAIL BA
2 248-248D NTA2000 SGS HAND RAIL TIE
2 248-249D NTA2000 SGS HAND RAIL TUBE
40 800-029C CLAMP HOSE GRASS SEED
5 800-120C NUT CLIP U-TYPE 5/16-18
40 800-324C NTA1300 SML SDS HOSE CLIP
5 802-007C HHCS 5/16-18X3/4 GR5
7 802-014C HHCS 3/8-16X3/4 GR5
12 802-017C HHCS 3/8-16X1 GR5
2 802-082C HHCS 1/2-13X1 3/4 GR5
2 802-714C HHCS M8X1.25X25 GR8.8 YLW
12 803-014C NUT HEX 3/8-16 PLT
2 803-169C NUT HEX FLG. LOCK 1/2-13 P
7 803-209C NUT FLANGE LOCK 3/8-16 PLT
7 804-009C WASHER LOCK SPRING 5/16 PL
4 804-011C WASHER FLAT 3/8 USS PLT
12 804-013C WASHER LOCK SPRING 3/8 PLT
4 804-113C WASHER FLAT 1/2 USS HARD P
1 805-327C PIN ROLL 6MM X 35MM PLT
1 818-003C DECAL SLOW MOVING VEHICLE
1 818-245C GRASS SEED RATE DECAL
10 838-160C DECAL 3 COLOR STRIPE 2.50
1 838-161C DECAL LOGO&GP F/STRIPE 4 X
1 838-357C DECAL NTA2000
1 838-374C DECAL ROTATION ARROW CW
1 838-467C DECAL SMALL SEEDS DANGER
150 990-171R HOSE 5/8 PVC
Qty. Part No. Part Description
