Great Plains Yield-Pro 1625 Planter 2004 User Manual
Page 13
12/12/2005
402-188M
Great Plains Mfg., Inc.
13
Installation Instructions
402-187A 2004 Yield-Pro® 1625 Planter Base Update 2005 Kit
Your kit includes:
4
148-283H
COULTER COMMAND CYLINDER PIN
1
401-226M
MANUAL OP 12 & 16 ROW YP PLTR
2
401-258H
YP HITCH PARK SUPPORT STAND
2
401-262H
PARK STAND MOUNT
2
401-267H
TRANSPORT SUPPORT HOOK WLDMT
2
402-158H
16R CASTER LOWER WLDMT
1
402-188M
MANUAL 2004 YP BASE UPDATE 2005
32
403-105D
IDLER PIVOT
32
403-115H
IDLER BRACKET WELDMENT
1
403-164H
MANIFOLD FRONT TOP WELDMENT 2
1
403-165H
SEAL HOLDER WELDMENT
1
403-188H
HOPPER WATER GUARD WELDMENT
1
403-189H
SEED STRAINER GRATE WLDMNT
1
403-316D
AIR DEFLECTOR
1
403-317D
SEED CHAMBER DIVIDER LH
1
403-318D
SEED CHAMBER DIVIDER RH
1
403-336D
METER DRIVE ADAPTER
2
800-064C
HOSE CLIP 13/16 ID
4
800-073C
GREASE ZERK 1/4-28 X 90-DEG
12
800-082C
CABLE TIE .31 X 21.5 6DIA 120LB
64
800-085C
SNAP RING EXT 1 HEAVY
4
802-318C
HHCS 3/8-16 X 5 GR5
4
802-800C
HWH #12-14 X 3/4
4
803-014C
NUT HEX 3/18-16 PLT
4
803-020C
NUT HEX 1/2-13 PLT
4
804-015C
WASHER LOCK SPRING 1/2 PLT
2
804-028C
WASHER FLAT 1 USS PLT
1
805-024C
PIN ROLL 3/16 X 1 1/2 PLT
4
805-212C
PIN WIRE SNAP LOCK 3/8 X 2 1/2
2
806-060C
U-BOLT 1/2-13 X 6 1/32 X 7 1/4
2
807-260C
SPRING COMP 1.460D .148W X 4.0LG
1
816-478C
AUX METER TOP SEAL
2
816-479C
SEAL TOP CORNER
4
816-480C
HOSE WRAP 3.0-4.5 X 24 LG VELCR
64
817-083C
PRESS WHEEL ARM PIVOT BUSHING
64
817-406C
IDLER 1 PC 2.38 X 1.0 X 1.062
1
817-624C
FAN INLET RAIN SHIELD
1
890-179C
SILICON 35YR CLEAR 10 OZ
9
990-228R
SPIRAL HOSE WRAP 1 ID PLASTIC
Qty.
Part No.
Part Description
402-180A Yield-Pro® 1625 Planter Fertilizer Update Kit 2005
Your kit includes:
Qty.
Part No.
Part Description
32
829-089C
NOZZLE BODY 3/4 WET BOOM CL
2
830-380C
EL 3/4 MNPT X 3/4 FNPT SS
2
830-381C
AD 3/4 MNPT X 3/4 HB SS
32
830-383C
CP 1/4 PUSH LOK POLY
2
838-823C
DECAL YP FERTILIZER LEVEL
