8 S3T & Reel Great Plains Manufacturing, Inc.
550-487M 12/22/2011
5-Section Fold Catch Assembly
Refer to Figure 3
Note: The catch assembly is only used on 5-section
outer wings. Be sure to mount the bent catch
towards center of machine on both sides.
1. Attach catch assembly to inside of arm assembly
with the mounting plates . Secure with 1/2 x 3 1/2
hex bolts in top holes and 1/2 x 3 hex bolts in
bottom holes, 1/2 lock washers and 1/2 nuts.
2. Align arm assembly 3 7/8” from rear of arm to rear of
rear angle iron as shown.
3. All bolts may be tightened to specs, See “Torque
Values Chart” on page 22.
1
2
3 4
