6 S3T & Reel Great Plains Manufacturing, Inc.
550-487M 12/22/2011
Reel Following S3T
Refer to Figure 3
1.
Slide spring over tube of reel arm assembly .
Align other end of spring to tube on front plate of
arm assembly and let the rest of the reel arm
assembly rest on the pad towards rear of arm
assembly .
2. Secure reel arm assembly to arm assembly with
3/4 x 4 hex bolt and 3/4 top lock nut. Tighten top
lock nut snug but do not torque as arm needs to
pivot.
Note: Adjust nut on reel arm assembly snug to hold
spring on round tube on front plate of arm assem-
bly . When rest of drag is installed, set the pre-
load pressure on spring, See “5-Section Fold
Catch Assembly” on page 8.
Note: See Layout drawings pages 8-16 for proper reel
placements.
3. Attach reel assemblies to rear plates of reel arm
assembly with 3/4 x 4 1/32 x 4 1/2 u-bolts , 3/4
lock washers and 3/4 nuts.
4. All u-bolts may be tightened to specs, See “Torque
Values Chart” on page 22.
1 2
1
3
2
3
2 3
4
5 3
3
6
2 7
