Legend:
➊
= 1st revision;
➋
= 2nd revision;
➌
= 3rd revision;
●
= use up existing stock;
⊗
= not interchangeable;
⊗
➀ ➋
= for example: revision 2 is not interchangeable w/revision 1
117-055P
Ref.
Part No.
Part Description
Comments
2-2
Box and Frame
2
1.
119-270H
LADDER AND STAND WELDMENT
2.
802-226C
HHCS 1/2-13X2 3/4 GR5
3.
804-016C
WASHER FLAT 1/2 SAE PLT
4.
119-237D
LADDER SPACER
5.
802-159C
HHCS 5/16-18X1 GR5
6.
804-036C
WASHER FLAT 5/16 SAE PLT
7.
804-015C
WASHER LOCK SPRING 1/2 PLT
8.
803-020C
NUT HEX 1/2-13 PLT
9.
117-052H
12’ LEVEE SEEDER FRAME
9
117-053H
10’ LEVEE SEEDER FRAME
S/N TT1139-
9
117-070H
10’ LEVEE SEEDER FRAME
S/N TT1140+
10.
117-300D
DIVERTER SPACER TUBE
11.
804-009C
WASHER LOCK SPRING 5/16 PLT
12.
803-008C
NUT HEX 5/16-18 PLT
13.
117-296D
12’ END DIVERTER PANEL
13
117-298D
10’ END DIVERTER PANEL
14.
117-297D
12’ CENTER DIVERTER PANEL
14
117-299D
10’ CENTER DIVERTER PANEL
15.
802-034C
HHCS 1/2-13X1 1/4 GR5
16.
806-110C
U-BOLT 5/8-11 X 3 1/32 X 4 1/2
17.
117-051H
LEVEE SEEDER MOUNT WELDMENT
18.
804-022C
WASHER LOCK SPRING 5/8 PLT
19.
803-021C
NUT HEX 5/8-11 PLT
20.
117-301D
UNIVERSAL MOUNTING BAR
21.
803-011C
NUT LOCK 5/16-18 PLT
22.
802-390C
HHCS 5/16-18X3 1/4 GR5
23.
117-061H
PLOW STAND WELDMENT
24.
805-232C
PIN WIRE SNAP LOCK 3 1/2
11/14/2001
