Page 21
Legend:
➊
= 1st revision;
➋
= 2nd revision;
➌
= 3rd revision;
●
= use up existing stock;
⊗
= not interchangeable;
⊗
➀ ➋
= for example: revision 2 is not interchangeable w/revision 1
117-055P
Ref.
Part No.
Part Description
Comments
4-2
Drive
4
1.
802-097C
HHCS 1/4-20X2 1/2 GR5
2.
117-285D
FLOW CONTROL VALVE - PAINTED
3.
117-054H
HYD MOTOR AND VALVE MOUNT
4.
804-006C
WASHER LOCK SPRING 1/4 PLT
5.
803-006C
NUT HEX 1/4-20 PLT
6.
806-021C
U-BOLT 3/8-16 X 3 1/32 X 4
7.
808-024C
SPKT 40B12 X 1 BORE
8.
136-096D
CHAIN RL #40 76 PITCHES
9.
802-017C
HHCS 3/8-16X1 GR5
10.
804-013C
WASHER LOCK SPRING 3/8 PLT
11.
803-014C
NUT HEX 3/8-16 PLT
12.
117-302D
CHAIN GUARD
13.
810-407C
HYD MOTOR EATON
14.
802-672C
HHCS 1/2-13X4 1/2 GR5 SPTHD
15.
817-025C
NO. 40 12T IDLER SPKT.
16.
803-036C
NUT HEX JAM 1/2-13 PLT
17.
804-016C
WASHER FLAT 1/2 SAE PLT
18.
804-015C
WASHER LOCK SPRING 1/2 PLT
19.
803-020C
NUT HEX 1/2-13 PLT
20.
822-032C
FLANGETTE 52 MST
LS10 S/N TT1019+ LS12 SS1004+
21.
822-060C
BEARING 1 BORE W/LOCK COLLAR
LS10 S/N TT1019+ LS12 SS1004+
22.
802-282C
RHSNB 5/16-18X1 GR5
LS10 S/N TT1019+ LS12 SS1004+
23.
804-036C
WASHER FLAT 5/16 SAE PLT
LS10 S/N TT1019+ LS12 SS1004+
24.
804-009C
WASHER LOCK SPRING 5/16 PLT
LS10 S/N TT1019+ LS12 SS1004+
25.
803-008C
NUT HEX 5/16-18 PLT
LS10 S/N TT1019+ LS12 SS1004+
11/14/2001
