Page 19
Legend:
➊
= 1st revision;
➋
= 2nd revision;
➌
= 3rd revision;
●
= use up existing stock;
⊗
= not interchangeable;
⊗
➀ ➋
= for example: revision 2 is not interchangeable w/revision 1
117-055P
Ref.
Part No.
Part Description
Comments
3-2
Metering System
3
1.
118-527D
12’ LS FEEDERCUP TRAY
1
118-526D
10’ LS FEEDERCUP TRAY
S/N TT1139-
1
118-606D
10’ LS FEEDER CUP CHANNEL
S/N TT1140+
2.
118-529D
10’ LS FEEDERCUP SHAFT
2
118-528D
12’ LS FEEDERCUP SHAFT
3.
817-074C
SEED CUP SLEEVE
4.
817-075C
SEED CUP ASSEMBLY
Includes items 23 through 29.
5.
890-190C
PM SEED CUP SPROCKET
6.
890-350C
5/8 SHAFT LOCKING COLLAR
7.
801-035C
SCREW SET 5/16-18 SKT KP X 3/8
8.
802-004C
HHCS 1/4-20X3/4 GR5
9.
803-194C
NUT HEX WHIZ 1/4-20 PLT
10.
118-725S
LS BEARING ASSEMBLY
Includes items 16 through 20.
11.
802-014C
HHCS 3/8-16X3/4 GR5
12.
804-013C
WASHER LOCK SPRING 3/8 PLT
13.
118-432D
6 5/8 BOX DVDER FOR 8 1/2 ROW
14.
118-530D
10 1/2 BOX DIVIDER
15.
118-341D
2SNT SEED BOX DIVIDER CLIP
16.
808-269C
SPKT 40B25 X .630 SQ BORE
17.
118-336D
FEEDER CUP BEARING HOUSING
18.
822-103C
BRG 30MM B X 55MM OD
19.
800-004C
SNAP RING EXT BASIC 1.880
20.
800-107C
SNAP RING INT 2.165
21.
803-088C
NUT HEX LOCK 1/4-20 FLG
22.
802-196C
HFSS 1/4-20X5/8 GR5
23.
801-057C
SCR SELF TAP 8X3/8 TYPE25 BT
24.
817-073C
SEED CUP WASHER RETAINER
25.
817-004C
NYLON WASHER-SPLIT
26.
817-068C
SEED CUP LEFT HALF
27.
817-070C
SEED CUP DOOR
28.
817-069C
SEED CUP RIGHT HALF
29.
817-071C
SEED CUP ADJUSTMENT HANDLE
30.
118-575D
SHAFT COUPLER
LS10 S/N TT1019+
LS12 S/N SS1004+
1/17/2002
