Page 13

Legend:
➊
= 1st revision;
➋
= 2nd revision;
➌
= 3rd revision;
●
= use up existing stock;
⊗
= not interchangeable;
⊗
➀ ➋
= for example: revision 2 is not interchangeable w/revision 1
117-055P
Ref.
Part No.
Part Description
Comments
2-6
Box and Frame
2
Box Assembly 10 Foot (S/N TT1140+)
1.
118-828H
10’ LEVEE SEEDER BOX WELDMENT
2.
118-402D
SEED BOX PARTITION
3.
119-295H
10’ LID WELDMENT
4.
890-221C
12-20 x 90 LB GAS SPRING
5.
803-011C
NUT LOCK 5/16-18 PLT
6.
803-199C
NUT HEX FLANGE 5/16-18 PLT
7.
802-387C
HFS 5/16-18X3/4 GR5
8.
803-169C
NUT HEX FLG. LOCK 1/2-13 PLT.
9.
119-190D
HANDLE
10.
804-011C
WASHER FLAT 3/8 USS PLT
11.
802-203C
HFSS 1/2-13X1 1/2 GR5
12.
802-092C
RHSNB 5/16-18X3/4 GR5
13.
804-036C
WASHER FLAT 5/16 SAE PLT
14.
803-008C
NUT HEX 5/16-18 PLT
15.
313-076S
LID HINGE ASSEMBLY PS25120
Includes items 20,21.22 and 23
16.
119-153D
LATCH CASTING MACHINED
17.
807-106C
SPRING .540 O.D.X 1 1/4 X.054W
18.
119-154D
LID HANDLE
19.
802-425C
HHCS 5/16-18X1 1/4 NYL
20.
803-209C
NUT FLANGE LOCK 3/8-16 PLT
21.
313-186D
LID HINGE PIVOT
22.
313-176D
LID HINGE BASE PLATE
23.
802-411C
RHSNB 3/8-16X2 GR5
24.
118-403D
BEARING CUTOUT COVER, 47 MST
25.
802-017C
HHCS 3/8-16X1 GR5
11/14/2001
