Legend:
➊
= 1st revision;
➋
= 2nd revision;
➌
= 3rd revision;
●
= use up existing stock;
⊗
= not interchangeable;
⊗
➀ ➋
= for example: revision 2 is not interchangeable w/revision 1
117-055P
Ref.
Part No.
Part Description
Comments
2-4
Box and Frame
2
Box Assembly 12 Foot (10 Foot S/N TT1139-)
1.
802-203C
HFSS 1/2-13X1 1/2 GR5
2.
119-190D
HANDLE
3.
118-487D
SEED BOX IDLER COVER RH
Only on 12’ box 1/31/2002 -
4.
804-011C
WASHER FLAT 3/8 USS PLT
Only on 12’ box
5.
804-013C
WASHER LOCK SPRING 3/8 PLT
Only on 12’ box
6.
802-079C
HHCS 3/8-16X1 1/4 GR5
Only on 12’ box
7.
118-415H
12’ SEED BOX
7
118-413H
20’ SEED BOX LH
8.
802-387C
HFS 5/16-18X3/4 GR5
9.
118-486D
SEED BOX IDLER COVER LH
Only on 12’ box 1/31/2002 -
10.
803-169C
NUT HEX FLG. LOCK 1/2-13 PLT.
11.
803-209C
NUT FLANGE LOCK 3/8-16 PLT
12.
118-402D
SEED BOX PARTITION
13.
803-199C
NUT HEX FLANGE 5/16-18 PLT
14.
313-076S
LID HINGE ASSEMBLY PS25120
Includes items 11,16,17 and 18.
15.
802-017C
HHCS 3/8-16X1 GR5
16.
313-186D
LID HINGE PIVOT
17.
313-176D
LID HINGE BASE PLATE
18.
802-411C
RHSNB 3/8-16X2 GR5
19.
119-153D
LATCH CASTING MACHINED
20.
807-106C
SPRING .540 O.D.X 1 1/4 X.054W
21.
119-154D
LID HANDLE
22.
804-036C
WASHER FLAT 5/16 SAE PLT
23.
802-425C
HHCS 5/16-18X1 1/4 NYL
24.
119-231H
LID 126 11/16 SEED
24
119-229H
LID 106 SEED
25.
803-011C
NUT LOCK 5/16-18 PLT
26.
890-221C
12-20 x 90 LB GAS SPRING
27.
118-403D
BEARING CUTOUT COVER, 47 MST
2/1/2002 +
28.
802-569C
HFSS 3/8-16X1 1/2 GR5
29.
123-520D
SEED BOX REINFORCEMENT STRAP
30.
802-092C
RHSNB 5/16-18X3/4 GR5
31.
118-052H
BOX PARTITION UPPER PAD
3/10/2004
