Great Plains Manufacturing, Inc.
Liquid Fertilizer Rate
43
2013-09-23
401-406B
CDS-John Blue
®
Rates, 1820 cm Swath
This table is in U.S. customary units, and is based on an
1820 cm (661 inch) swath, covering models
YP2425-2470 and YP2425F-2470. See page 41 or
page 42 for other spacings.
For dual-pump operation, rates are double the values
shown in the chart.
CDS-John Blue
®
Reference Data, 1820 cm
Use the data below with the CDS-John Blue
®
115797-01
slide chart or with the CDS-John Blue
®
internet
calculator.
(When ordering this slide chart use the envelope number
115698-91.)
Plant at or below 13 kph with the 47T Driving sprocket
installed. The pump is rated for 450 rpm maximum, which is
exceeded at and above 14 kph.
Pump Type
(•) Piston Pump
NGP-6050 Series
Data
Preference
(•) English Units
Application
Rate
Drive
System
(•) Ground Drive
Loaded Radius: 17.55in
Swath Width
(use
1
⁄
2
of these values
for a two-pump manifold)
1680 cm
1680 cm
Drive
(Required):
(Optional):
(Optional):
(Optional):
25
15 or 47
__
__
Driven
(Required):
(Optional):
(Optional):
(Optional):
15
15
__
__
Sprocket Ratio
(for slide chart)
Driving 15T:
Driving 47T:
1.67
5.22
Ground Speed
5 mph
a
a. Gallons per acre is independent of speed between
2 mph and 8 mph. See advisory below.
Driving Sprocket
47
15
Dial Setting
2
3.0
19
3
4.5
28
4
5.9
37
5
7.4
2.4
47
6
8.9
2.8
56
7
3.3
65
8
3.8
75
9
4.3
84
10
4.7
94
11
5.2
103
12
5.7
112
13
6.2
122
14
6.6
131
15
7.1
140
16
7.6
150
17
8.1
159
18
8.5
168
19
9.0
178
20
9.5
187
21
9.9
196
1680 cm
34130B
Gallons
per
Acre
Liters
per
Hectare
Figure 19
CDS-John Blue
®
Slide Chart
26156
