18 YP2425 & YP2425F Table of Contents Appendix Great Plains Manufacturing, Inc.
401-406B Table of Contents Appendix 2013-09-23
Finger Meter Adjustments
The finger pick up meter has an adjustable brush. The
brush has been pre-set to the optimum setting for most
seed sizes.
Finger Meter Brush Adjustment
The brush reduces or eliminates “doubles” (delivering
two seeds per finger), but if set too aggressively can
cause “skips” (delivering no seed on some fingers). As
needed, adjust for minimal doubles and skips.
Note: These instructions describe the current finger
pickup meter shipped with new Great Plains
planters, which has an integrated adjustment lever
for the brush. If you have pre-existing finger meters,
there is some chance that you may have previous
model meters, adjusted by screwdriver rather than
lever. If so, rely on counting detents to determine
the setting. Not all have 9 detents.
Refer to Figure 7
The adjustable brush provides additional flexibility to
accommodate a wide range of seed sizes. Use lever
to gently rotate the brush into position.
Settings range from 1 to 5, with detents at each half step,
for a total of 9 detents. The factory default setting is 2
1 ⁄
2
.
Although the numbers are molded into the meter
housing, only “1” and “5” may be visible. To ensure
consistency, rotate lever
fully counter-clockwise (1),
and count detents as you advance it to the desired
setting.
Use the general guidelines in the table below to adjust
the brush position to your seed size and shape. The
numbers listed correspond to the numbers printed on the
outer housing of your meter.
If there is a decal on your meter, its units are in pounds
per 80,000 seed bag. The table below includes seeds
per pound.
Figure 7
Finger Meter Brush Lever
25276
5
1
4
3
2
L
L
L
Bag Weight Seeds Per Brush Seeds Per Bag Weight
(80,000 seeds) Pound Setting Kilogram (80,000 seeds)
Rounds
65 lbs 1230 or less 1 2710 or less 29.5 kg
65 to 55 lbs 1230 to 1450 2 2710 to 3195 29.5 to 24.9 kg
55 to 45 lbs 1450 to 1780 3 3195 to 3925 24.9 to 20.4 kg
45 to 35 lbs 1780 to 2300 4 3925 to 5070 20.4 to 15.9 kg
35 lbs 2300 or more 5 5070 or more 15.9 kg
Flats
45 lbs 1780 or less 1 3925 or less 20.4 kg
45 to 35 lbs 1780 to 2300 2 3925 to 5070 20.4 to 15.9 kg
35 lbs 2300 or more 3 5070 or more 15.9 kg
29633
