TABLE OF CONTENTS TABLE OF CONTENTS
1.0 OVERVIEW ......................................................................................... 1
1.1
Modes of Operation ................................................................. 2
1.1.1 Internal Mode .................................................................. 2
1.1.2 External Mode................................................................. 2
1.1.3 Charging Mode ............................................................... 3
1.2 Brightness ................................................................................ 3
1.2.1 Degree of Rotation Adjustment .................................... 4
1.2.2 Pulse Duration Adjustment ........................................... 5
2.0 PREPARATION FOR USE .................................................................. 5
2.1
Power ........................................................................................ 5
2.2 Input / Output Connectors....................................................... 6
3.0 LED STROBE OPERATION................................................................ 7
3.1
Adjusting the Flash Rate - RPM .............................................. 8
3.2 Multiply or Divide By 2............................................................. 8
3.3 Menu Options ........................................................................... 8
3.3.1 MODE .............................................................................. 9
3.3.2 BRITE (Brightness) ...................................................... 10
3.3.3 SAVE .............................................................................. 10
3.3.4 LOAD ............................................................................. 11
3.3.5 UNITS ............................................................................ 11
3.3.6 BKLIT (Backlight) ......................................................... 12
3.3.7 DECPT (Decimal Point) ................................................ 12
3.3.8 INPUT (Input Pulse Polarity) ....................................... 12
4.0 USING THE STROBOSCOPE TO MEASURE RPM ........................ 13
5.0 BATTERIES ....................................................................................... 15
5.1
Low Battery Indication........................................................... 15
5.2 Charging the Batteries........................................................... 15
5.3 Battery Disposal ..................................................................... 16
6.0 SPECIFICATIONS ............................................................................. 17
7.0 OPTIONS AND ACCESSORIES / SENSORS .................................. 19
