13
In the External Time Delay mode the fl ash is delayed 0.01 to
1000 msec after each external trigger pulse. The display will show
the TIME icon, the delay in milliseconds on the top line and will
indicate
MSECS on the lower line. The knob adjusts the amount of
delay in milliseconds, counterclockwise to increase and clockwise
to decrease.
In the Auto (Virtual RPM) mode the fl ash is automatically
delayed in increasing amounts after the external trigger pulse so
that the image appears to rotate at a slow (Virtual) speed, RPM.
The display will show the AUTO icon, the virtual speed in RPM
on the top line and will indicate
VRPM (Virtual RPM) on the lower
line. The knob adjusts the virtual speed in RPM, counterclockwise
to increase and clockwise to decrease.
3.8
Menu
The Menu allows settings of basic setup options – displayed
decimal places, backlight on or off, positive or negative edge
for input and output signal and blanking. The menu is entered
by pressing the MENU button and using the knob to scroll through the
menu options as described below. The top display line shows
Setup.
To select a menu option, press the MENU button again.
3.8.1
Decimal Places
Sets the number of decimal places shown on the display for
numeric. After pressing the MENU button rotate the knob until the
display bottom line shows
DECPT and press the MENU button
again. The top line of the display will show the number of decimal
places (2, 1, none) selected by rotating the knob. Press the MENU
button to select, then any other key to exit. The display will show
DONE and return to the normal readout.
