Musica MUR2EM
1-2 NS-1005-7140
All specifications subject to change without notification. All rights reserved. Copyright © 2005 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.
Specifications
Installer Requirements
This manual assumes the installer:
 knows how to install a Musica system,
 knows how to use basic installation tools such as an RJ-45 crimper to terminate
CAT5e wire.
 has pulled all necessary wire to the locations where the preamp, keypads, and
speakers are to be installed.
 understands basic Microsoft
®
Windows
®
commands such as how to browse, create
folders, save files, etc.
For more information on meeting the prerequisites, contact NetStreams Technical
Support at 866-353-3496.
Table 1-1
Specifications
Item Specification
Network Interface RJ-45 (10BASE-T) ethernet
Management Internal HTTP server
System Firmware Flash ROM standard (firmware can be
downloaded from the TCP/IP host (TFTP) or over
the serial port)
LEDs  Network link
 Ethernet activity
 Custom (red)
Physical Dimensions  • Length: 3.876 in (9.846 cm)
 • Width: 1.680 in (4.267 cm)
 • Depth: 0.999 in (2.537 cm)
Weight  Weight: 2.29 oz (6.50 g)
Power 9-30VDC @ 370 mA
Environmental  Storage temperature: -40º C to +90º C (-40º F
to +194º F)
 Operating temperature: 0º C to 60º C (32º F to
140º F)
 Relative humidity: 5% to 90% (non-
condensing)
 Altitude: 12,000 Feet (3658 Meters)
Agency Approvals  FCC Part 15, Class A
 EN 55022
 EN5J024
 VCCI
 AS 3548
 UL60950
 CSA 22.2 NO.60950
 EN 60950
