21

Appendix C

~ Serial Commands

Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760

The GT1524 accepts serial commands through the serial port. The commands in this

manual pertain only to the GT1524. RS-232 serial port protocol is 9,600 (default),

19,200, or 38,400 baud; 8 bits, 1 stop bit, no parity.

Conventions

The following typographic conventions are used in this document to describe the

different serial commands. Use the Command structure section and the examples as

a guide when creating your serial commands.

Convention

Description

Parameters enclosed in < > indicate a mandatory parameter.

[X]

Parameters enclosed in [ ] indicate an optional parameter.

1-8

Parameters separated by a - indicate a range between the values.

4,7,9

Parameters separated by a , indicate a list of available values.

MREF

Words in uppercase bold indicate command text.

Command structure

Commands can be either UPPERCASE or lowercase. Also, extra spaces or tabs

between arguments in text commands are allowed. Return values are always in

uppercase. In order for a command to be recognized by the serial port, the command

must be terminated by a carriage return.

The structure of serial commands is as follows: COMMAND [X] [X]

COMMAND

is the command text

[X] [X]

represents any additional options in the order that they appear in

the command descriptions that follow

Error codes

Error 1 (Future)

Error 2 Could not extract a command from the string received

Error 3 Serial overrun

Error 4 Reserved

Error 5 Invalid parameter

Error 6 Unrecognized command

Appendix C: Serial Commands
