Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2011 QuoizelInc.
7of7
STEP 9 Install Bulb
-
A. This fixture uses candelabra bulbs with candelabra
screw bases. Maximum 60 watts.
B. Insert bulb and screw snugly into place.
Bulb
Figure 10
Socket
STEP 10 Install Bulb
-
A. Place the Shade (I) over the Bulb, seat into the Shade
Holder as shown.
Your fixture pendant lamp is now assembled and ready to
use. Enjoy!
Shade
Shade
Holder
Bulb
Assembly Instruction Sheet #IS-TRY2824BA
For Style TRY2824BA
Figure 11
October2011
