Quoizel TFLU2822K Luxe User Manual
Page 2
TFLU2822K
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2of7
FINISH: MYSTIC BLACK
GND
2.4mm
13Ga
QUOIZEL
R
6”
12”
57.5”
OVERALL HEIGHT INCLUDES
(4) 6” RODS AND (6)12” RODS
(4)100W A19
Medium Base Bulbs
(Not Supplied)
8.5"
20.5"
5"
20" Dia.
21.5" Dia.
1"
9012EXK
9006EXK
ROD EXT MYSTIC BLACK 12"L X 0.5"D
ROD EXT MYSTIC BLACK 6"L X 0.5"D
6
4
3
G2987SH
SHADE TIFFANY BODY 20"D X 5"H
1
1
2
3
