7
Specifications
Introduction
Operational
Output concentration range
Carrier flow rate (nominal)
Dilution flow rate (nominal)
Dilution flowmeter accuracy
Permeation chamber
Temperature range
Temperature setpoint accuracy
Temperature setpoint repeatability
Temperature equilibrium time (nominal)
Size
Operational modes
Remote mode control inputs
Operating Duty Cycle
Environmental
Operating noise emission (at 3 feet)
Ambient operating temperature
Operating humidity
Storage temperature
Storage humidity
Operating altitude
Physical characteristics
Dimensions (standard case)
Weight
Without internal pump
With internal pump
Unit power requirements
Voltage
Power consumption
Main fuse
Heater fuse
Power consumption
Options
Basic plumbing
Gas flow capacity
Operational
Fractional ppb to hundreds of ppm
76, 180, or 375 cc/min,
factory set and specified per unit
1,2,5,10,15, and 20 L/min full scale
+1% at each major flow setting above 3
+3% at 1,2, and 3 at 25°C ambient,
50% relative humidity and 760 mm Hg
30°C* to 110°C
*or 2°C above ambient, whichever is higher
+0.1°C (N.I.S.T. traceable) at any integral
temperature setting at or above 30°C
+0.05°C at any fixed ambient temperature
1.5 hour maximum
Accepts devices up to 23.5 cm (9.25") long
x 1.6 cm (0.62") diameter
Standby, zero, span 1, span 2, and remote
Contact closures capable of handling a
24 VDC, 12W inductive load
Continuous
55 to 60 dBa for units with internal pumps
45 to 50 dBa for units without
Safe operation from +5°C to 40°C
Optimum performance from +20°C to 35°C
0 - 95% relative humidity
+5°C to 40°C
0 - 50% relative humidity
10,000' MSL
Operational
43.2 cm (17") wide x 60.3 cm (23.75") deep x
26.7 cm (10.5") high
21.3 kg (47 ibs)
26.4 kg (58 Ibs)
100-240 V~ 2.5A 50-60Hz
2.5 A maximum
6A
4A
150 W
Internal pump
Second gas supply inlet
Carrier stream bypass
Dilution stream bypass
0.4 - 1 liter/min
0.4 - 2 liters/min
0.4 - 5 liters/min
0.4 - 10 liters/min
0.4 - 15 liters/min
0.4 - 20 liters/min
