June 3, 2014 2 Manual 0-4933, Rev. AE
Supplied Parts
The following components are included in this kit:
item 4 only applies to the Transmig VAF 4HD, Transmig VAF 4, UltraFeed VAF-4 and UltraFeed VAF-4HD
items 7 & 8 only apply to the UltraFeed VA 4000 and VA 2000
Item No. Part Number Description Qty.
1 870707WBLK Base Plate, Trolley Kit 1
2 7977566 Swivel Caster, front 2
3 7977567 Fixed Caster, rear 2
4 See Note 1 M6 Countersunk Hex Socket Screw 4
5 See Note 1 M8 Spring Washer 14
6 See Note 1 M8 Hex Nut 14
7 See Note 1 M6 Spring Washer (not shown) 4
8 See Note 1 M6 Flat Washer (not shown) 4
Note 1: This part is available at most hardware stores.
Art # A-11632
1
2
3
4
5
6
Figure 2: Supplied Parts
