MAGNUM 610E PUMP OPERATION / MAINTENANCE MANUAL
PAGE 9
Air Supply
Pressure
(PSIG)
Discharge
Fluid
Pressure
(PSIG)
Air
Used
(SCFM)
Cycles
Per
Minute
Displacement
IN
3
Per
Cycle
20
0
3.9
170
10.4
20
10
2.8
105
9.3
30
0
5.6
190
10.5
30
15
4.0
120
9.4
40
0
7.0
198
10.5
40
20
5.4
125
9.6
50
0
8.4
205
10.5
50
25
7.2
130
9.7
60
0
10.2
208
10.6
60
30
8.4
128
9.4
Table 1: Consumption / Efficiency
NOTE: Specification to be used to size regulators and control valves.
Figure 3-1: Pressure & Capacity Chart
NOTE: Test information is based on specific conditions and limited sampling.
Use for general reference only.
