MAGNUM 610E PUMP OPERATION / MAINTENANCE MANUAL
PAGE 13
4.2 RECOMMENDED SPARE PARTS
KR610E-00-A Spares Rebuild Kit, which includes:
Part No
Qty
Description
KD610-00-A
1
Diaphragm Kit
Includes:
(2)
(2)
C0100
98001422
Diaphragm Sets
Main Seals
11001015
1
Protective Cap Set
1610B0022
1
Shaft
98001415
4
Check Ball
98001976
2
Shaft Seal
98002334
4
O-Ring, PTFE
AM084
2
Check Cap Seal
W0151
2
Fiber Optic Target
In critical applications, a spare pump and oscillator control module are
recommended to minimize down time.
4.3 TOOLS
The following tool kit is recommended as standard service equipment.
KT610E-00-A Tool Kit, which includes:
Part No
Qty
Description
98001225
2
3/8” Nut Driver
98002327
1
Tool Case
98003225
1
3/8x1/4 Drive Socket
98003305
1
1/4” Drive Handle
T000B0014
1
Check Sleeve Removal Tool
T000B0020
1
Check Sleeve Insertion Tool
T0146
1
3/4” Pin Tool
T16002104
1
Shaft Bullet
T0144
1
Cleaning Tool
