PAGE 16 MAGNUM 610E PUMP OPERATION / MAINTENANCE MANUAL

Lay the pump on the slave head side.

Remove the master head.

Remove the main seal and diaphragms.

Remove the body assembly.

Remove the slave side set of diaphragms and main seal.

Remove tie bolts.
NOTE: All polypropylene and fluoroplastic parts, when disassembled, should be
thoroughly washed and be free from acid residue for handling purposes.
4.7.a Body Disassembly

Remove check bore caps using 3/4 ” pin tool and remove seals.

Remove sleeves with sleeve removal tool, check balls and O-rings.

Unthread one push plate from the shaft.

Remove remaining push plate and shaft from body.

Unthread second push plate from shaft.

Remove shaft seals from the shaft bore, taking care not to damage the shaft
bore or shaft seal grooves.

Remove base mount from body.
4.8 ASSEMBLY
4.8.a Body Assembly
NOTE: For easy installation, check sleeves that fit too tightly should be placed in
a freezer prior to assembly to assist insertion. Body must be upside down with
check port extending over a table edge so that parts remain assembled during
insertion of sleeves. (See Figure 4-1.)
