MAGNUM 610E PUMP OPERATION / MAINTENANCE MANUAL PAGE 3
1 INSTALLATION
1.1 UNPACKING
After unpacking, the pump should be checked for any damage that may have
occurred during shipment. Damage should be reported to the carrier
immediately.
The following items should be included within the shipping container:
Qty Item Description
1 610E Magnum 610E Pump
1 M610E Operation/Maintenance Manual
1.2 TIE BOLT TORQUE
The tie bolts on the pump are tightened before leaving the factory. However,
relaxation may occur due to handling, material creep, or other unforeseen
events. Trebor recommends that all eight tie bolts be re-tightened upon pump
install. The following procedure should be used.
1. Remove black tie bolt caps (Item 22 in 4.4 Parts Illustration) from both
sides of all 8 tie bolts.
2. Apply 42 in-lbs. of torque to each slave side bolt while holding the master
side bolt stationary. A star-pattern is advised.
a. The master side is the left side of the pump if you are looking at
the fluid ports.
3. Replace tie bolt caps.
1.3 UTILITIES / HOOK-UP FOR 610E PUMP
It is recommended that the pump be installed no more than 15° from level to
maintain its self-priming ability and pumping efficiency. This pump mounts on a
quick release base for easy installation.
Air Inlet: 1/4” FNPT (3/8” Dia. [8mm] supply tube minimum).
Fluid Ports:
3/4” FNPT - additional adaptor port options available.
Inlet/Outlet adaptor fluid fittings and Surge Suppressor
require torqueing during pump installation. See Section 2
for hook- up diagram and torque values
