PIX 270i User Guide and Technical Information
87
Specifications
Audio Recording and Playback
Record/Playback • 64 channels record/playback @ 48.048 kHz sample rate and lower
• 32 channels record/playback @ 88.2 kHz sample rate and higher (Audio Only Mode)
• Simultaneous Analog, AES/EBU, HDMI, SDI, Dante, or MADI. Selectable per channel
Analog Audio
Inputs • 8 Balanced, line-level inputs on DB-25.
• Ch1,2 also on XLR
Outputs • 8 Balanced, line-level outputs on DB-25.
• Ch1,2 also on XLR
Frequency Response 10Hz-40kHz, +/- 0.5dB re 1kHz
THD + Noise 0.004% max (1kHz, 22Hz-22kHz)
Input and Output Topology Fully electronically balanced, RF, ESD, short, and overload protected;
pin-2 hot, pin-3 cold
Line Output Clipping Level +18dBu
Front Panel Headphone 1/4” with gain control
Line Input Clipping Level +26dBu
Input Impedance 10k
Digital Audio
Sample Rate / Bit Depth • 44.1 kHz, 47.0952 kHz, 48 kHz, 48.048 kHz, 88.2 kHz, 96 kHz
• 24-bit
AES3 • 8 channels in and out via DB-25, 110 ohm, 2 V p-p.
• Accepts 32k, 44.1k, 48k, 96k, 192k sample rates. with SRC at input.
HDMI • 8 channels embedded HDMI input
• 8 channels embedded HDMI output.
• Accepts 32k, 44.1k, 48k, 96k, 192k sample rates.
SDI • 16 channels embedded SDI input
• 16 channels embedded SDI output
• 48k sample rate, with sample rate conversion
Dante • 64 channels
• 48kHz input and output
MADI • 64 channels (32 channels with 88.2 kHz and 96 kHz sampling rates)
• BNC and SC (Optical) I/O
• BNC and SC output simultaneous; BNC or SC input select
File Storage
Disk Format exFAT
PIX-CADDY 2 mounted drives Two, front-mounted Sound Devices approved 2.5-inch drives (or Sound Devices approved CF
cards with PIX-CADDY CF. Poly WAV recording only)
eSATAp conected drives Two, rear panel eSATAp ports for drives meeting Sound Devices specifications, supplies 5V
@ 2A
