PIX 270i User Guide and Technical Information
v. 2.10
Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
78
Se
tup Menu Op
tions
On-Screen Display
#
Parameter Name
Description
Options
1
ABS Time
Display of absolute record time.
» On
• Off
2
File Codec
Display of current file codec
» On
• Off
3
File Name
Display of current file name
» On
• Off
4
File Resolution/Rate
Display of current file resolution
» On
• Off
5
Audio Source
Display of audio input levels for channels 1 and 2
» On
• Off
6
Input - Video
Display of input audio source and channel count
» On
• Off
7
Headphone Source
Display of headphone audio source
» On
• Off
8
Audio Metering
Display mode of audio meters for inputs 1 and 2
• Off
» Top (wide)
• Top (thin)
• Bottom (thin)
• Left (thin)
• Right (thin)
9
Time/date
Display of time of day and date
» On
• Off
10
Timecode
Display of current timecode value
» On
• Off
11
Drive (D1) status
Display status of Drive 1
» On
• Off
12
Drive (D2) status
Display status of Drive 2
» On
• Off
13
Drive (D3) status
Display status of Drive 3
» On
• Off
14
Drive (D4) status
Display status of Drive 4
» On
• Off
15
RS-422 Status
Display status of connected RS-422 controller
» On
• Off
16
Cue Marker
Display cue marker information during playback
» On
• Off
17
Sync Reference
Display current Sync Reference
» On
• Off
18
Group Number
Displays [Network - Group] setting
» On
• Off
19
IP Address
Displays current PIX 270i IP Address
» On
• Off
