Coaxial Digital Audio Output

Requires an coaxial digital audio cable
(not included)

1. Plug the coaxial digital audio

cable into the COAXIAL DIGITAL
AUDIO OUTPUT on the player and
a coaxial digital audio input on a
television or home theater system.

The standard color for coaxial digital

The standard color for coaxial digital
audio ports is orange.

audio ports is orange.

2. Adjust the connected television or

home theater system to the input
source used in step #1.

3. This will allow audio from the

player to play on the connected
television or home theater system.

To play video from the player

To play video from the player
through your television, follow the

through your television, follow the

through your television, follow the
instructions for Composite Video

instructions for Composite Video

instructions for Composite Video
Output, Component Video Output,

Output, Component Video Output,

Output, Component Video Output,
or HDMI Output.

or HDMI Output.

Better Audio Quality

CEN

5.1 CHANNEL OUT

Connecting the Player to the Subwoofer

CAUTION

RISK OF ELECTRIC SHOCK

D O

N O T

O P E N

INPUT

AUX

DVD

OUTPUT

OFF

POWER

CEN

5.1 CHANNEL OUT

Requires an RCA stereo audio cable (included)

1. Connect the RCA stereo audio

cable to the RCA STEREO AUDIO
OUTPUT on the player and the RCA
STEREO AUDIO INPUT (DVD) on the
subwoofer.

2. Power the subwoofer on and press

the SOURCE button to switch to DVD
mode.

3. Audio played on the player will now be

output through the subwoofer and it’s
connected speakers.
