SONIQ H10 - Manual (Page 12)

Specification Basic Operation
22 21
4. Sound Control
(1).MUTE
①.Press“MUTE”, and then the machine enters into mute state. The screen shows“MUTE”.
②.Press“MUTE”again or adjust the volume value, and then it will return to normal value.
(2) Turn up/down Volume
① .Press“VOL+”on the top panel or“VOL+”on the remote control to turn up the volume. The
screen will show the added volume value. Press“VOL-”on the top panel or“VOL-”on the
remote control to turn down the volume. The screen will show the decreased volume value.
②.You can adjust the volume between 0-32.
(3).Turn up/down Bass
① .Press“BASS+”on the remote control to turn up the bass. The screen will show the added
bass value. Press“BASS-”on the remote control to turn down the bass. The screen will show
the decreased bass value.
②.You can adjust the bass between -7~7.
(4).Turn up/down Treble
① .Press“TRE+”on the remote control to turn up the treble. The screen will show the added
treble value. Press“TRE-”on the remote control to turn down the treble. The screen will show
the decreased treble value.
②.You can adjust the treble between -7~7.
Adjust the bass and treble properly, in case that it worsens the tune. Tuning the bass value and
treble value to “0” is recommended.
Note:
1. H10 Power Amplifier
Power Output: 6W+6W (8Ω)
Frequency Response: 20Hz~22kHz (±1dB)
2. USB Storage Device
Support Type A USB Socket, Full Speed (12 Mbps)
3. FM Tuner
Tuner:FM Stereo
Frequency Range: 87.5~108.0 MHz (0.1 MHz Step Length)
Noise Limitation Sensitivity: 5uV
4. AUX Input Sensitivity
AUX IN(RCA):500 mV (RMS)
5. USB Sound Card
Support Type B USB Socket, Full Speed
Sample Rate: 32k, 44.1k, 48 kHz
6. Headphone Output
Headphone Socket:Stereo Headphone between 32Ω～300Ω
7. Speaker (H10)
Power: 50W
Impedance: 8Ω
Sensitivity: 89dB
Frequency Response: 60~24000Hz
8. Parameters
Alternative Voltage:100~240V,50/60Hz
Power Consumption:60W
Dimension of H10:188mm×165mm×68mm
Dimension of Speaker:178mm×165mm×172mm
Net Weight of Main Machine: 2.1 kg
Net Weight of Speaker: 6.5 kg
Working Condition: Temperature：-10 ~40 Moisture：20%～80%
Storage Condition:Temperature：-20 ~70 Moisture：20%～90%
°C °C
°C °C
