User instructions – SONIQ B500 User Manual

Page 11

background image

-18-

-19-

TOP MENU: Select this option to return to the discs main title screen.

POPUP MENU: Select this option and depending on how the disc is authored a pop up menu

will appear adding extra functionality.
For example, a chapter selection menu may appear on screen.

Connecting USB/SD Device

Connecting USB /SD Device Supported Audio, Video, Picture files types
Video: MPEG-4 files. Music: mp3 files .wma files. Picture: jpeg files.
USB storage devices with supported files stored on a FAT32partition will be recognized.
SD storage devices with supported SD MAX2GB (FAT16) and 4 GB SDHC ~ 32 GB FAT32

NOTE:

The USB device must be formatted as a

FAT32 drive, NTFS and other filesystem types

are not supported.

USB interface output voltage of DC5V (± 0.1V) Maximum output current 0.5 A
If USB drives the work more than 0.5 please increase A current USB driver external power
supply, to see the appended drawings:

NOTE: USB/SD Device do not support 3D video files.

Playing a CD Disc

1. Press the

STANDBY button to power on the unit. When powered on the STANDBY/POWER

light will be blue.

2. Press the

OPEN/CLOSE button to open the disc tray, “OPEN” will appear on-screen. Insert a

disc with the label facing upwards into the tray.

3. Press the

OPEN/CLOSE button to close the tray “CLOSE” will appear on-screen, then

READING” will briefly display. After loading, the menu screen of the disc should appear. Use

the navigation buttons to select your required option and press the

ENTER button to select.

4. To stop playback, press the

STOP button. Press the PLAY button again to resume playback

from where you left off. If the

STOP button is pressed a second time the resume option is

cancelled.

5. Press the

PAUSE ll button to pause playback. To resume playback press either the PAUSE ll

or

PLAY ► button.

SELECTING TRACKS USING THE NUMBER BUTTONS

Press the number button(s) corresponding to the track number you would like to play, then press
the

ENTER button and the player will start to play your specified track.

SELECTING TRACKS USING THE NUMBER BUTTONS

During playback, pressing the

SKIP ►►l buttons will select the playing tracks and begin

playback.
Again Press the

SKIP l◄◄ buttons will select the previous tracks and begin playback, one more

press makes it move to the beginning of the previous tracks.

FORWARD >> / REVERSE << SEARCH

During playback, press either the

FAST/FWD ►► or FAST/REV ◄◄ buttons to advance the

disc forward or backwards at double speed

X2. To increase the advance rate, press the button

again repeatedly to cycle between:

X2, X4, X8, X16 and X32.

To resume normal playback press the

PLAY button.

When the

SUB MENU button is pressed, a sub menu will appear on-screen.

The content of this menu depends on the disc being played at the time.

Select a category using the navigation buttons, press the

ENTER button to select the option.

Most options have sub menus attached to expand further options.

Some categories are disc dependant, but a description of most can be found below.

PLAYBACK

Repeat: Select to repeat ALL, TRACK, RANDOM ( like shuffle ) or OFF.

Data Playback

PLAYBACK OF DATA (PICTURE AUDIO) DISC/ SD/USB

Press the

BD/SD/USB button to select the input you wish to view files from.

After a short period a list of available folders and files will appear on-screen.Use the navigation
buttons to select an image or a folder and press the

ENTER button to start playback or to open

the folder. To return to the previous folder navigate up to the “..” icon at the top of the list and
press

ENTER.

To return to the selection menu during playback press the

RETURN button.

NOTE: These below options are limited to the folder list screen and won't be available

during a slide show.

User Instructions

User Instructions

External USB

Interface

USB Drive

Native USB

Interface
