Series MNK 200-150-315
Page 25
9230-053-en Revision 12
TM 8195 Edition 03/2011
10 Sectional drawing
10.1 Legend
100 housing
122 blind cover
158 can insert
159 can
183 support bracket
211 pump shaft
213 drive shaft
230 impeller
314/x axial bearing
321/x radial ball bearing
330 bearing pedestal
339 plain bearing pedestal
344 Lantern
361 rear bearing cover
401 housing gasket
404 Bearing pedestal gasket
412/x O-ring
415/1 centering gasket
421/x rotary shaft seal
509/1 intermediate ring
523/x shaft sleeve
529/x bearing sleeve
545/x bearing bush
552/3 tightening washer
554/x washer
557/2 contact disc
636/x lubricating nipple
858 drive magnet assembly
859 inner magnet assembly
901/x hex. screw
902/1 stud screw
914/x hex. socket screw
920/1 hex. nut
934/4 lock washer
940/1 key
953/1 Wavy spring washer
Additional to Oil bath lubrication
411/1
seal ring
421/x rotary shaft seal
638/1 constant-level oiler
655/1 oil drain plug
672/1 venting/filling plug
