Connections, Remote dipole/monopole switching (continued), Connector panel – Revel S30 User Manual
Page 18: Mode/tweeter controls
Figure 15. How to connect a
remote control system to the
relay input terminals on the rear
panel of the REVEL PERFORMA
S30 surround loudspeaker.
CONNECTIONS
REMOTE DIPOLE/MONOPOLE SWITCHING
(Continued)
REVEL PERFORMA S30
Owner’s Manual
18
REVEL
PERFORMA S30
Rear
Revel
Northridge, California
Made in U.S.A.
Serial Number
xxxx xxxx
Connector Panel
Set MODE Control To
“Remote”
Mode/Tweeter
Controls
(on side)
Dipole
M
onopole
R
em
ote
0
Hi Frequency
Level (dB)
+1
-1
Serial Number
xxxx xxxx
To Switch Output (6.8~12 V
dc
) On
Multi-Channel Controller System
