Brinkmann ELITE SERIES 4685 User Manual
Page 15
14
Step 21
Connect 12' Hose with quick
disconnect to side burner valve and
main burner gas manifold by tightening
hose nuts. Re-connect igniter wire to
electrode.
NOTE: Leave the back panel off until
the end of conversion and all
gas leak testing has been done.
Step 22
Reattach back panel by placing panel
over bolts and siding down. Secure
four back panel bolts.
Hose Nuts
Back Panel Bolts
Igniter Wire
