Brinkmann ELITE SERIES 4685 User Manual
Page 14
13
Step 19
Place side burner assembly on
right side of grill body by lifting
assembly up and sliding down
over bolts. Replace M4 X 10mm
bolt into side burner assembly front
panel and grill body. Tighten four
M6 X15mm bolts.
Step 20
Reattach bezels and control knobs
to main control panel.
Main Control
Panel Bezels
Right Side Of Grill
