6
Mounting the Fixture
The standard mount (MTP-KL41)
comes with a 3/8” Lollipop that
clamps into a grip head. The ball and
socket mount allows the fixture to be
oriented in a broad range of angles.
Align the center pin of the mounting
plate to the center hole on the
mating plate.
Rotate plate clockwise until the
four shoulder rivets drop into the
receptacle. A locking pin will snap
into place when the plate is properly
seated.
The yellow wire loops provide
attachment points for a safety chain.
Gelling the Fixture
Restricting the airflow around the lamps can cause the lamp to
operate hotter. This increased heat will raise the lamp’s color
temperature and green spike. Therefore, it is recommended to
clip gels to the Doors of the Fixture.
Do Not clip gels to louver.
Do Not block the fixture ends in a manner that restricts airflow.
