20
Kino Flo 4Bank Fixture Dimensions
Barndoor Weight
Fixture Style Length Width Depth Width w/Lamps
2ft 4Bank 27.00” 13” 3.5” 6.5” 7.5 lbs
4ft 4Bank 52.00” 13” 3.5” 6.5” 11.5 lbs
Fixture Specifications
Kino Flo Double Fixture Dimensions
Barndoor Weight
Fixture Style Length Width Depth Width w/Lamps
2ft Double 27.00” 7.5” 3.5” 6.0” 4.7 lbs
4ft Double 52.00” 7.5” 3.5” 6.0” 7.7 lbs
Kino Flo Single Fixture Dimensions
Barndoor Weight
Fixture Style Length Width Depth Width w/Lamps
2ft Single 27.00” 4.5” 3.5” 3.5” 2.7 lbs
4ft Single 52.00” 4.5” 3.5” 3.5” 4.3 lbs
