5
Mounting Procedures
Baby Offset Arm
A 180 degree turn is all that is required to loosen the
mount for orientation.
To adjust the tension on the lock lever, pull handle
away from mount. This disengages the handle from the
screw mechanism and allows the lever to be reoriented.
You can also use a screwdriver to adjust the tension.
Pull back on handle and adjust screw.
Lollipops are interchangeable.
MTP-L Kino 41 Lollipop w/ 3/8” Pin (10mm)
MTP-LB Kino 41 Lollipop w/ Baby Receiver (16mm)
MTP-LBS Kino 41 Lollipop w/ Baby Receiver
Short (16mm)
Mounted on a baby stand Mounted to pipe grid Note: When hanging in a
studio, loop a safety cord
through the strain-relief ring
provided on the back of the
fixture.
The Baby Offset Arm (MTP-B41F) allows fixtures to mount on the center of a
stand or can also be under slung from a baby stand to use as an up light.
