Remote Dimmer Operation
The Remote Dimmer (DIM-5), sold separately, is designed to remotely dim the
Tegra 4Bank.
Insert the dimmer cable into the receptacle marked:
REMOTE DIM.
Inserting the dimmer cable will automatically disable
the onboard dimmer.
Insert the other end of the dimmer cable into the
Remote Dimmer
(DIM-5).
DMX Operation
DMX Addressing
Prior to hanging any instruments, set the DMX address
of each fixture.
Push the tabs above or below the number window to set
the address. (Valid addresses range from 001 to 512.)
The light above the address block will illuminate if a
DMX signal is present.
Tip: Power is not required to set DMX addresses.
Therefore, DMX addresses can be set for each fixture
prior to hanging.
IMPORTANT!
The dimmer board/light console should have its channel set to LINEAR light
output response. (LINEAR response is the default setting on most dimmer
boards.)
